Fine Coated Ground Calcium Carbonate
1750 mesh, D50 2 µm, D97 max 8 µm.
The five grades look alike to the eye. What sets them apart is particle size, shown in the specification below. Photographs are for illustration.
Fine Coated Ground Calcium Carbonate, 1750 Mesh, Stearic Acid Coated
K-GCC-C2 is ground to 1750 mesh and then surface treated with stearic acid. Its median particle size is 2 µm and its top size is 8 µm.
The coating repels moisture and helps the powder mix evenly into polymers.
- Mesh
- 1750 mesh
- D50
- 2 µm
- D97
- max 8 µm
Fineness
What this fineness is suited to.
A D50 of 2 µm and a D97 of up to 8 µm gives a fine, even filler with few coarse particles. Combined with the stearic acid coating, it suits PVC pipes, profiles and cables, plastic film, masterbatch, rubber and sealants.
Mesh
1750 mesh
Mesh is a sieve based name for fineness. A higher mesh number means a finer powder.
D50
2 µm
D50 is the median particle size. Half of the particles are smaller than this figure and half are larger.
D97
max 8 µm
D97 is the size below which 97% of the particles fall. It describes the coarse end of the powder, so a lower D97 means fewer large particles.
Specification
Specification table.
| Property | Value |
|---|---|
| Product code | K-GCC-C2 |
| Type | Coated, stearic acid |
| Mesh | 1750 mesh |
| D50 (median particle size) | 2 µm |
| D97 (coarse end) | max 8 µm |
| CaCO3 content | 97% minimum |
| Whiteness | 93% or higher |
| Brightness | 93% or higher |
| Moisture | 0.3% maximum |
| Oil absorption | 10 to 16 g per 100 g |
| pH | 9 to 10 |
| Specific gravity | About 2.7 |
| Mohs hardness | 3 |
| Stearic acid coating | About 1% by weight |
Mesh, D50 and D97 define the grade. Other values are typical. A technical data sheet and certificate of analysis are provided with every quotation.
Benefits
Key benefits.
- Stearic acid coating repels moisture
- Disperses evenly in polymers
- Fine, with a top size of 8 µm
- Flows well in processing equipment
Packing
Packing options.
- 25 kg and 50 kg polypropylene bags
- Jumbo bags, 1 to 1.25 tonne
- Palletised or loose loaded
- Custom branding on request
See Quality and Logistics for shipping terms and documents.
Tell us what you need and we will send a quotation.
Send the product, grade, quantity and destination port. A technical data sheet and certificate of analysis are provided with every quotation.
